| 外胎成型机主要参数 | |
| Main Technical Parameter for Tyre Building Machine | |
| 机型 | Type | WT800-1519-2P(4P) | WT801-1821-2P(4P) | WT801-0814-2P(4P) | |
| 轮胎种类 | Size of tire | 机车胎 | 机车胎 | 速克 | |
| 廉纱层数 | Nylon cord | 2 PLY(4PLY) | 2 PLY(4PLY) | 2 PLY(4PLY) | |
| 廉纱卷直径(最大）Cord fabric roll diameter (max) | | 450mm | 450mm | 450mm | |
| 衬布最大直径 Inner cloth roll diameter (max) | | 400mm | 400mm | 400mm | |
| 成型筒转速 | Revolution of drum | 180/60rpm | 180/60rpm | 300/100rpm | |
| 主轴马达 | Main drive motor | pole change motor 1.5kw/4P | |
| 辊压马达 | Under stitcher motor | pole change motor 0.4kw/4P | |
| 供纱机马达 | Ply servicer motor | 1/2HPx4Px1/20/each ply | |
| 压缩空气 | Compressed air | 5-7kg/c㎡
| |
| 机械尺寸 | Overall dimension | 2300Lx2200Wx2050H | |
| 成型速度 | Building speed | 2PLY building 500pcs/8hrs 4PLY building 400pcs/8hrs | 2PLY 600pcs/8hrs 4PLY 450pcs/8hrs |
